Tripp Lite HDBaseT HDMI Over Cat5e Cat6 Cat6a Extender Kit with Serial / IR Control 4K x 2K 150m 500ft Item # 471972
Thank you, you will now be redirected to comparisons.
Just a moment while we prepare the page
Check In-Store Availability
The BHDBT-K-SI-ER HDBaseT Extender Kit allows you to transmit HDMI audio and video, RS-232 serial and IR Remote Control signals up to 500 feet(150 m) over a single Cat5e/6/6a cable, including a 1920 x 1080(1080p) signal @ 60 Hz. Add up to five Tripp Lite BHDBT-TR-SI-ER transceivers(sold separately) between the transmitter and receiver units to further expand the range up to 3,000 feet(900 m) with a monitor connected via HDMI port to each transceiver.You can also control RS-232 serial devices, such as touchscreen displays or scanners, at baud rates up to 115 Kbps. The BHDBT-K-SI-ER's 2-way IR Remote Control feature(@ 39 KHz) lets you control your Blu-ray player using its remote when at the remote monitor or control your remote monitor using its remote when at the Blu-ray player. Locking HDMI ports (ideal for use with Tripp Lite's High-Speed HDMI cables with locking connectors, such as P569-006-LOCK) on both the transmitter and receiver prevent cables from coming loose or undone, ensuring an intact signal.The BHDBT-K-SI-ER supports 7.1-channel surround sound, DTS-HD and Dolby TrueHD audio, as well as 3D video, EDID and HDCP. Included mounting hardware lets you attach each unit to a wall, rack or pole. There's no software to download or install, and you can have the BHDBT-K-SI-ER Extender Kit set up and ready to go quickly.
|brand name||Tripp Lite|
|Certifications & Standards||TAA; CE; FCC|
|form factor||Pole-mountable; Wall Mountable; Rack-mountable|
|Graphics Modes||Full HD|
|Input Voltage||5 V DC; 120 V AC; 230 V AC|
|Maximum Operating Distance||500 ft|
|Maximum Video Resolution||1920 x 1080|
|Media Type Supported||Twisted Pair|
|Number of Input Devices Supported||1|
|Number of Output Devices Supported||1|
|package contents||Transmitter; Receiver; IR-IN and IR-OUT Cables; 3.5 mm Male to DB9 Female Adapter Cable; 3.5 mm Male to DB9 Male Adapter Cable; 2 x External Power Supplies (Input: 100-240V, 50/60 Hz, 0.5A Output: 5V, 3A); Mounting Hardware; Owner's Manual|
|ports||2 Ethernet (RJ-45); 1 HDMI in; 1 HDMI out|
|Twisted Pair Cable Standard||Category 6a|
|warranty length||1-year limited|
|Weight (Approximate)||1.05 lb|
|Show More ▾|
HDBaseT HDMI, Serial and IR Control over Cat5e/6 Extender Kit (Transmitter and Receiver)
uncompressed HDMI audio/video, RS-232 serial and IR control signals up to 500
feet over a single Cat5e/6/6a cable. Tripp Lite’s HDBaseT HDMI over Cat5e/6
Extender Kit comes with both the transmitter (local) and receiver (remote)
units and sends the signals over user-supplied Cat5e/6/6a cable. The BHDBT-K-SI-ER
is a cost-effective solution for digital signage applications in schools,
retail locations, tradeshow booths, conference rooms and anywhere you need to
extend multiple types of signals over extra-long distances.
The BHDBT-K-SI-ER extends a 1920 x 1080 (1080p) HDMI signal @ 60 Hz up to 500 ft. To expand and extend the reach of your installation, add up to five Tripp Lite BHDBT-TR-SI-ER transceivers between the transmitter and receiver units. Each transceiver supports connection of an HDMI display and extends your transmission range up to 3,000 ft. at 1080p resolution. With the BHDBT-K-SI-ER, you have the flexibility to house the source devices in a secure, remote location while still delivering the signals to devices in another area.
Plug-and-Play Convenience and Versatile Mounting Options
The BHDBT-K-SI-ER does not require software or drivers, making setup simple. It includes mounting hardware for wall, rack and pole installations. Locking HDMI ports on the transmitter and receiver units prevent disconnection when used with HDMI cables with locking connectors, such as Tripp Lite’s P569-006-LOCK HDMI cables.
Serial signals and IR control signals travel over a single Cat5e/6/6a cable along with HDMI video. This eliminates cable clutter and reduces installation costs. The BHDBT-K-SI-ER supports 115 Kbps full-duplex baud rates for scanners and touchscreen monitors. Two-way 39 KHz IR remote control functionality allows use of an HDMI source’s remote control in the same location as a monitor connected to the receiver. This gives you the ability to control your Blu-ray™ player with its remote while standing at the remote monitor (and vice versa).
Compatible with Current Standards
Designed to deliver high-quality results, the BHDBT-K-SI-ER supports 7.1-channel surround sound, DTS-HD and Dolby TrueHD audio. It also supports 36-bit Deep Color (12 bits per channel) and CEC pass-through. This extender kit is compatible with 3D video, EDID and HDCP 2.0.
The BHDBT-K-SI-ER is compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases.
One-Year Warranty and Environmentally Responsible Design
The BHDBT-K-SI-ER comes with a one-year warranty. It’s manufactured in compliance with strict RoHS specifications, reflecting Tripp Lite’s commitment to environmental responsibility.
- Transmit HDMI audio/video, RS-232 serial and IR control signals over a single Cat5e/6/6a cable
- Ideal for use in schools, retail locations, tradeshow booths and conference rooms
- Extends a 1920 x 1080 (1080p) HDMI signal @ 60Hz up to 500 ft.
- Controls RS-232 serial devices at baud rates up to 115 Kbps
- Allows control of a Blu-ray player from the location of a remote monitor
- TAA-compliant for GSA Schedule purchases
- One-Year Warranty
What's in the Box
- HDBaseT HDMI over Cat5e/6 Extender Kit with Serial and IR Control (Transmitter and Receiver)
- IR-In Cable
- IR-Out Cable
- 3.5 mm Male to DB9 Female Adapter Cable
- 3.5 mm Male to DB9 Male Adapter Cable
- (2) External Power Supplies (Input: 100-240V, 50/60 Hz, 0.5A; Output: 5V, 3A)
- Mounting Hardware
- Owner's Manual
