Tripp Lite SRW6U Wall Mount Enclosure Cabinet Item # 902362
Thank you, you will now be redirected to comparisons.
Just a moment while we prepare the page
Check In-Store Availability
The SRW6U SmartRack 6U Low-Profile Switch-Depth Wall-Mount Rack Enclosure Cabinet is designed to house EIA-standard 19-inch rack equipment in network wiring closets, retail locations, classrooms, back offices and other areas with limited floor space where you need equipment to be secure, organized and out of the way. Constructed from heavy-duty steel with a durable black powder-coated finish, the cabinet has a maximum load capacity of 90 kgs (200 lbs).The side panels and front door lock securely to help prevent damage, tampering or theft. The front, top, bottom and removable side panels are vented, which allows air to flow freely and keep equipment cool. The reversible front door can open left or right by rotating the cabinet 180° before mounting. Convenient top and bottom ports allow easy cable routing.The SRW6U comes fully assembled and ready to mount to the wall, or use Tripp Lite’s optional SRCASTER rolling caster kit to make it a mobile rack. Square and threaded mounting holes and numbered rack spaces make equipment installation easy. The vertical mounting rails adjust in 7/8-inch increments to accommodate equipment up to 16.5 inches deep, such as network switches and patch panels.
|brand name||Tripp Lite|
|form factor||Wall Mountable|
|Maximum Weight Capacity||140 lb|
|Rack Width||19 in.|
|warranty length||5-year limited|
6U Wall Mount Rack Enclosure Cabinet with Door & Sides
Are you running out of IT floor space? Tripp Lite’s SRW6U
Wall-Mount Rack Enclosure Cabinet is the ideal storage solution for standard
rackmount equipment in any environment where floor space is limited. With its
sturdy wall-mount bracket and heavy-duty steel frame, it supports a maximum
weight capacity of 200lbs and provides 6U of rack space. The SRW6U is packed
with premium features designed to simplify rack equipment installations: top
and bottom cable routing ports, perforated door and side panels to promote
efficient airflow, adjustable vertical mounting rails and more.
The swing direction of the lockable front door can be reversed by rotating the enclosure 180 degrees before installation. The front door locks to provide secure access and is perforated to promote efficient airflow.
Modular Side Panels
The SRW6U includes two lockable, removable side panels for ease of installation and service access. The side panels are perforated to allow generous airflow.
Front and rear pairs of rails adjust in one-inch increments. Adjustment is quick and convenient—simply unscrew the rails, slide them to the desired depth and restore the screws. Square mounting holes and included hardware support any standard 19-inch rack equipment. Rack spaces are numbered for easy reference.
Vented Top and Bottom Panels with Cable Cutouts
The top and bottom panels of the SRW6U are furnished with vents designed to help remove warm air from the enclosure and draw in cool air by convection. They also support installation of standard user-supplied case fans. The top and bottom panels are also provided with ports for cable routing through the enclosure. Removable covers block unused cable ports.
The optional SRCASTER rolling caster kit adapts the enclosure to floor-standing and roll-away applications under desks, tables or counters. Additional SmartRack Cooling Solutions and Rack Accessories are available for a variety of applications: air conditioning, heat removal, airflow management, cable management, rack shelves, security & monitoring, mounting and power.
5-Year Warranty and Environmentally Responsible Design
The SRW6U comes with a 5-Year Warranty and is manufactured to meet strict RoHS specifications, reflecting Tripp Lite's commitment to environmental responsibility. The SRW6U provides physical equipment and media security required for PCI DSS (Payment Card Industry Data Security Standard) compliance.
- Houses standard 19-inch rack equipment in 6U of space
- Supports maximum weight capacity of 200 pounds
- Lockable, removable side panels are ventilated to allow generous airflow that keeps equipment cool
- Vented top and bottom panels help remove warm air and draw in cool air
- Ships fully assembled for quick installation
- Front mounting rails adjust in 7/8-inch increments from 3 to 16.5 inches deep
- Meets PCI DSS compliance
- 5-year product warranty
Founded in 1922 in Chicago, Illinois, Tripp Lite is a leading manufacturer of products to power, connect, house and protect your equipment. From the largest data center to the smallest home office, Tripp Lite products keep your equipment running effectively and efficiently. Whether you need to supply power to servers and have reliable battery backup, connect high-resolution video sources to displays and digital signs, or organize and secure IT equipment in rack enclosures, Tripp Lite has the complete solution. Plus, before and after your purchase, our Chicago-based, in-house technical support specialists are available to assist you by phone, email and live chat. With over 90 years of quality products and service, Tripp Lite is a brand you can trust.
