Item # | 532393 |
Manufacturer # | GAC1037UN |
64-bit Processing | Yes |
Audio Channels | 7.1 |
BIOS Features | DMI 2.0 support, ACPI 2.0a support, SMBIOS 2.6 support, UEFI BIOS |
BIOS Type | AMI |
brand name | Gigabyte |
Bus Clock | 1333 MHz, 1066 MHz |
Chipset Manufacturer | Intel |
controller type | Serial ATA/600; Serial ATA/300; Ultra ATA/133 (ATA-7) |
depth | 6.7 in. |
eSATA | Yes |
form factor | Mini ITX |
Gigabit Ethernet | Yes |
Graphics Controller | Intel HD Graphics |
Graphics Controller Manufacturer | Intel |
Graphics Controller Memory | 1 GB |
Graphics Memory Accessibility | Shared |
Graphics Memory Technology | DDR3 SDRAM |
Hardware Features | DualBIOS, Q-Flash, AutoGreen, All-Solid Capacitor motherboard Design, On/Off Charge, Ultra Durable 4 Classic, Intel Smart Connect Technology, Clear CMOS Button |
Hardware Monitoring | CPU core temperature, CPU fan tachometer, chassis fan tachometer, system voltage |
HDMI | Yes |
Integrated Processor Cache | 2 MB |
Integrated Processor Core | Dual-core (2 Core) |
Integrated Processor Manufacturer | Intel |
Integrated Processor Model | 1037U |
Integrated Processor Speed | 1.80 GHz |
Integrated Processor Type | Celeron |
Internal Interfaces | 1 x audio - header; 4 x USB 2.0 - header; 1 x parallel - header; 1 x serial - header |
manufacturer | GIGABYTE Technology, Inc |
Max Processors Qty | 1 |
Max Size | 16 GB |
Maximum Memory | 16 GB |
Memory Form Factor | DIMM |
Memory Speed Supported | 1.60 GHz; 1.33 GHz |
Memory Standard | DDR3-1600/PC3-12800; DDR3-1333/PC3-10600 |
Memory Technology | DDR3 SDRAM |
model | GA-C1037UN |
Number of IDE Interfaces | 1 |
Number of Memory Slots | 2 |
Number of PCI Slots | 1 |
Number of SATA Interfaces | 3 |
Number of Total Expansion Slots | 1 |
Onboard Audio Header | Yes |
Onboard Parallel Header | Yes |
Onboard Serial Header | Yes |
Onboard Video | CPU Dependent Video |
ports | 1 audio line in; 1 audio line out; 1 eSATA; 2 Ethernet (RJ-45); 1 HDMI out; 1 microphone; 4 onboard USB 2.0; 2 PS/2; 1 serial; 4 USB 2.0; 1 VGA 15-pin D-sub |
Power Connectors | 4-pin ATX12V connector, 24-pin main power connector |
Power Supply Supported | ATX12V |
Processor Socket | Socket BGA-1023 |
Product Line | Ultra Durable 4 Classic |
PS/2 Port | Yes |
Sound Controller Manufacturer | Realtek |
Sound Controller Model | ALC887 |
Storage Interfaces | SATA-600 -connectors: 1 x 7pin Serial ATA - 1 devices; SATA-300 -connectors: 2 x 7pin SATA, 1 x 7pin eSATA - 3 devices; ATA-133 -connectors: 1 x 40pin IDC - 2 devices |
Total Number of Onboard USB Ports | 4 |
Total Number of USB Ports | 4 |
Total Processor Supported | 1 |
warranty length | 3-year limited |
Weight (Approximate) | 1.90 lb |
