Tripp Lite's P036-006-2C19, 1.83 m (6-ft.) Universal AC Splitter Power Cord, allows you to connect two devices with C20 connections, such as blade server chassis, to one power outlet. Cuts down on cabling, as well as frees up space on UPS systems, Surge Protectors, PDUs, etc. Main trunk cable measures 47" from C20 plug to the splitter housing, 3" housing, and 22" each on the two C19 legs.
|brand name||Tripp Lite|
|Compatibility||Computer; Blade Server Chassis|
|Connector||2 x power IEC 60320 C19|
|Connector (Second End)||Power IEC 60320 C20|
|Connector on First End||2 x IEC 60320 C19|
|Connector on Second End||1 x IEC 60320 C20|
|cord length||6 in.|
|Current Rating||20 A|
|Device Supported||Computer; Server|
|frequency||50 Hz; 60 Hz|
|Rated Voltage||AC 100-250 V|
|Voltage Rating||110 V AC; 220 V AC|
|warranty length||limited lifetime|
Power Two Heavy-Duty Network Devices from One Outlet
Lite’s Heavy-Duty Y Splitter Power Cord is the ideal solution for splitting
power to network devices that require a heavy-gauge power cord, such as
servers, network switches and devices with internal redundant power supplies.
Featuring two C19 connectors on one end and a C20 connector on the other, this
cable provides a reliable power connection from a single power source to your
equipment. Use the P036-006-2C19 to split power from a PDU or UPS outlet to
multiple devices, or power multiple outlets on a single device that has
internal redundant power supplies.
The P036-006-2C19 is manufactured using superior materials and is tested to UL standard 817 for optimal product safety. The high-quality connectors are molded for durability and have integral strain-relief for a secure connection. This SJTW cable has three 12 AWG conductors and a 20-amp rating.
Founded in 1922 in Chicago, Illinois, Tripp Lite is a leading manufacturer of products to power, connect and protect your equipment. With a large selection of connectivity products, Tripp Lite has everything from USB hubs and reversible USB cables to fiber-optic cables and over Cat5e/Cat6 signal extenders. Whether you need to connect high-speed networks to switches, routers and servers in your data center, or send high-resolution video signals to displays and digital signs, Tripp Lite has the complete solution. Plus, before and after your purchase, our Chicago-based, in-house technical support specialists are available to assist you by phone, email and live chat. With over 90 years of quality products and service, Tripp Lite is a brand you can trust.
