Item # | 845748 |
manufacturer | Garmin |
depth | 2.6 in |
weight | 1.2 lbs |
alarms | deep water, fish size, low battery, shallow water |
Transducer Type | Dual-beam |
Transducer Mount | Transom |
Maximum Depth | 600 ft |
Beamwidth | 14/45 degrees |
Operating Frequency | 80/200 khz |
Power Output (Peak to Peak) | 800 w |
Power Output (RMS) | 100 W |
built-in display type | fstn - 3.2 in x 3.1 in |
Resolution | 240 x 128 |
Display Diagonal | 4" |
color support | Monochrome |
color depth | 4-level grayscale |
Display Illumination | Yes |
digital camera use | see-thru technology, autogain technology, automatic settings backup, ultrascroll, fish symbol id, whiteline |
Low Voltage Power | dc 10 - 18 v |
Waterproof | Yes |
waterproof standard | ipx7 |
Included Accessories | mounting bracket, power cable |
Warranty | 1 year warranty |
Min Operating Temperature | 5 ¦f |
Max Operating Temperature | 158 ¦f |
