Tripp Lite HDMI Signal Booster Video Extender 1080p at 60Hz HDMI F/F TAA / GSA Item # 493886
Thank you, you will now be redirected to comparisons.
Just a moment while we prepare the page
Check In-Store Availability
Tripp Lite's B122-000-60 HDMI Signal Extender increases the distance a 1080p @ 60Hz(or 1920 x 1200) signal can be transmitted beyond the recommended 16-ft.(5M). It supports computer video resolutions up to 1920 x 1200, and HD resolutions up to 1080p @ 60Hz, at a maximum distance of 150-ft. from the source. Use standard P568-Series HDMI cables in most applications. When extending a 1080p @ 60Hz(or 1920 x 1200) signal more than 75 ft., use cable made with 24Awg wiring, such as the P568-100-HD.(Lengths over 100 ft. are available from Tripp Lite as a custom order) 24Awg HDMI cable is also needed when extending a 3D signal more than 50-ft.. A 3D signal can be extended up to 125-ft. using 24Awg HDMI cable. Simply connect the longer cable between the source and the B122-000-60, and the shorter cable(16-ft. or less) between the adapter and the monitor. Software or drivers are not required. External power is not required in most installations. HDCP compliant. Compliant with the Federal Trade Agreements Act(TAA) for GSA Schedule purchases.The B122-000-60 has been designed for use with Tripp Lite P568-Series HDMI cables. To ensure maximum distance and performance, it is recommended that you use Tripp Lite P568-Series HDMI cabling. For distances over 75-ft, 24AWG cable such as Tripp Lite's P568-100-HD is required.Although most installations will not require power, a Micro USB port is provided in the event power is needed. Using a Micro USB cable(such as Tripp Lite's UR05C-Series), connect the Micro USB port to a USB wall charger, the USB port on your monitor, or the USB port on a computer.
|brand name||Tripp Lite|
|Certifications & Standards||TAA|
|Maximum Extended Range||150 ft|
|warranty length||3-year limited|
|What's Included||B122-000-60 HDMI Extender; Manual|
Extend 1080p High-Definition Video up to 150 ft.
|Extend high-quality HDMI video up to 150 ft. from the source with Tripp Lite’s B122-000-60 HDMI Signal Booster/Active Extender. It’s a simple solution for delivering video beyond the 16 ft. HDMI distance limitation. The B122-000-60 allows the video source to be in a secure, remote location for controlled access while still delivering a signal to a display in another area. Use the B122-000-60 in schools, conference rooms, retail displays, trade show booths and anywhere else you need to display high-definition video. This extender supports computer video resolutions up to 1920 x 1200 and HD resolutions up to 1080p @ 60 Hz.|
The B122-000-60 has two HDMI female ports and is designed for use with Tripp Lite P568-series HDMI cables to extend an HDMI signal up to 150 ft. Connect your longer cable between the source and the extender and a shorter cable (16 ft. or less) between the extender and your monitor. For distances over 75 ft., a 24 AWG cable (such as P568-100-HD) is required. (Lengths over 100 ft. are available from Tripp Lite as a custom order.) The B122-000-60 can also extend a 3D signal up to 125 ft. (for 3D installations over 50 ft., use 24 AWG HDMI cable).
Supports the Latest Standards for Superior Performance
The B122-000-60 meets the latest industry standards to deliver high-definition results. It supports up to 36-bit Deep Color (12 bits per channel) for a vibrant picture and supports DTS-HD, Dolby TrueHD and 7.1 channel surround sound audio for high-quality sound. The B122-000-60 is HDCP compliant.
With no software or drivers to install, the B122-000-60's plug-and-play setup gets your application up and running quickly. External power is not required for most installations. However, a micro-B port is provided if needed. Use a micro-B cable (such as Tripp Lite’s UR05C-series) to connect the micro-B port to a USB wall charger or the USB port on your monitor or computer.
The B122-000-60 is compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases.
Three-Year Warranty and Environmentally Responsible Design
The B122-000-60 comes backed by a three-year warranty. It’s manufactured in compliance with strict RoHS specifications, reflecting Tripp Lite’s commitment to environmental responsibility.
- Extends a 1080p (60 Hz) HDMI signal up to 150 ft. from the source
- Supports computer video resolutions up to 1920 x 1200
- Extends a 3D signal up to 125 ft.
- Supports DTS-HD, Dolby TrueHD and 7.1 channel surround sound audio
- Complies with HDCP
- No external power required in most installations
- Complies with the Federal Trade Agreements Act for GSA Schedule purchases
- Three-year warranty
What’s in the Box
- B122-000-60 HDMI Signal Extender
- Owner’s Manual
