Tripp Lite Display Port to HDMI Over Cat5/6 Video Extender Transmittor & Receiver Item # 568562
Thank you, you will now be redirected to comparisons.
Just a moment while we prepare the page
Check In-Store Availability
The B150-1A1-HDMI DisplayPort to HDMI over Cat5/Cat6 Active Extender Kit includes a transmitter unit and a receiver unit that work in tandem to convert a DisplayPort audio/video signal to HDMI and then extend it to a projector, monitor or television up to 150 feet away. The kit is ideal for digital signs, trade shows, presentations, classrooms, churches, retail settings and other applications where the video source is located farther than convention cables allow. One Cat5e/6 cable connects the transmitter and receiver(for best results, use 24 AWG solid-wire Cat5e/6 cable, such as Tripp Lite's N202-Series). A built-in DisplayPort cable connects the transmitter to the source, while a built-in HDMI cable connects the receiver to the display. Included USB Micro-B cables connect the transmitter to a USB port on the DisplayPort computer or a USB wall charger(such as Tripp Lite's U280-002-W12), and connect the receiver to a USB port on the HDMI display or a USB wall charger. No external power supplies are needed. The B150-1A1-HDMI can extend a high-definition 1080i(60 Hz) signal up to 150 feet and a 1080p(60 Hz) signal up to 125 feet. In addition to crystal-clear video, including 24-bit True Color(8 bits per channel), the kit delivers full, rich stereo. Green and orange LEDs on both units indicate when they are receiving power from the USB Micro-B cables and sharing a signal. Easy to set up with no software or drivers to install. Works with all operating systems.
|brand name||Tripp Lite|
|Graphics Modes||Full HD|
|Maximum Operating Distance||150 ft|
|Maximum Video Resolution||1920 x 1080|
|Media Type Supported||Twisted Pair|
|Number of Input Devices Supported||1|
|Number of Output Devices Supported||1|
|ports||2 Ethernet (RJ-45); 1 HDMI out; 2 USB|
|Twisted Pair Cable Standard||Category 6a|
|warranty length||1-year limited|
|What's Included||Transmitter Unit; Receiver Unit; 2 x USB Micro-B Cables, 3 ft.; Owner's Manual|
|Show More ▾|
Converts a DisplayPort Signal to HDMI and Extends It Up to 150 Ft.
Tripp Lite’s B150-1A1-HDMI DisplayPort to HDMI over
Cat5/Cat6 Active Extender Kit includes a transmitter and a receiver that work
in tandem to convert a DisplayPort audio/video signal to HDMI, then extend it
to a projector, monitor or television up to 150 ft. away. You can save money
and use your existing HDMI display without the need to purchase a DisplayPort
monitor. This kit is ideal
for digital signage applications in classrooms, convention centers, churches,
retail environments, and other locations where the video source is located
farther than conventional cables allow.
The B150-1A1-HDMI can extend a high-definition 1080i (60 Hz) signal up to 150 ft. and a 1080p (60 Hz) signal up to 125 ft. In addition to crystal-clear video, including 24-bit True Color (8 bits per channel), the B150-1A1-HDMI delivers full, rich stereo when the DisplayPort source is enabled to support audio.
Uses Inexpensive Cat5e/6 Cables
One low-cost, user-supplied Cat5e/6 cable connects the transmitter and receiver. For best results, use 24 AWG solid-wire Cat5e/6 cable, such as Tripp Lite’s N202-Series.
With no software or drivers to install, the B150-1A1-HDMI’s plug-and-play setup gets your application up and running faster, no matter which major operating system you use. Built-in cables connect the transmitter to your DisplayPort source and the receiver to your HDMI display. The included USB Micro-B cables supply external power to the units. LEDs light up to show when the units are receiving power and sharing a signal. No other external power supply is needed.
The B150-1A1-HDMI is compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases.
Comes Backed by a One-Year Warranty
For peace of mind, the B150-1A1-HDMI comes backed by a one-year warranty. As part of Tripp Lite’s commitment to environmental responsibility, this extender kit is manufactured in compliance with strict RoHS specifications.
- Converts a DisplayPort signal to HDMI and extends it up to 150 ft. away
- Extends a high-definition 1080i (60 Hz) signal up to 150 ft. and a 1080p (60 Hz) signal up to 125 ft.
- Delivers crystal-clear video, including 24-bit True Color (8 bits per channel) and full, rich stereo when the DisplayPort source is enabled to support audio
- Uses inexpensive, readily available Cat5e/Cat6 cable
- Plug and play; no software or drivers required
- Works with all major operating systems
- TAA-compliant for GSA Schedule purchases
- One-year warranty
- Local Transmitter Unit
- Remote Receiver Unit
- (2) USB Micro-B Cables, 3 ft.
- Owner’s Manual
